Overview
The Kioti RX8040P sits in the RX40 sub-series of the Kioti RX range, offering a high-output, well-specified utility tractor for operators who need serious working capability without the added weight and cost of a factory cab. It is powered by a Daedong 4-cylinder turbocharged diesel engine producing 73.1hp (54.5 kW) at 2,600 rpm, with a maximum torque output of 240.5 Nm and a healthy 20% torque reserve to maintain power delivery under sudden increases in load.
The Power Shuttle transmission provides 20 forward and 20 reverse gears, giving a forward speed range up to 38.3 km/h. Direction changes are made via the Power Shuttle button on the gear lever without depressing the clutch pedal, which is a genuine working advantage for loader work, repetitive headland turns, and any task that calls for frequent forward and reverse transitions. The wide speed range covers both slow, precise implement work and practical transport speeds between fields or along roads.
The rear hydraulic system is designed to handle the full range of implements this class of tractor typically runs. The Category II three-point hitch with quick-type lower links lifts 2,533 kg at the hitch point and 1,963 kg at 24 inches behind. The independent rear PTO operates at 540 and 540E rpm with electro-hydraulic engagement and an Auto PTO function that couples PTO operation to the three-point hitch, automatically engaging and disengaging the implement drive as the linkage is lowered and raised at field headlands.
The turn-assist function reduces engine speed automatically when the steering angle reaches its limit, reducing fuel consumption and operator effort during repetitive headland turns. The air suspension seat and ergonomic controls ensure the operator stays productive and comfortable throughout a long working day. For operators who prefer a fully enclosed cab environment, Cardiff Lawn and Garden also stocks the RX8040PC version.
Key Features
- Daedong 73.1hp 4-Cylinder Turbocharged Diesel Engine: 73.1hp (54.5 kW) at 2,600 rpm, 240.5 Nm maximum torque, 20% torque reserve. Eco-friendly design with strong fuel efficiency for sustained daily use.
- 20×20 Power Shuttle Transmission: 20 forward and 20 reverse speeds with clutch-free direction changes via the gear lever button. Forward speed range up to 38.3 km/h for both precision field work and road transport.
- Category II Three-Point Hitch with Quick Lower Links: Maximum lift of 2,533 kg at the hitch point and 1,963 kg at 24 inches behind. Quick-type lower links for fast implement attachment and detachment.
- Independent Rear PTO: 540 and 540E rpm PTO with electro-hydraulic engagement and Auto PTO function for automatic headland management coupled to the three-point hitch raise and lower.
- Turn-Assist Function: Automatically reduces engine speed at the steering limit, cutting fuel consumption and reducing operator effort on repeated headland turns.
- Air Suspension Driver Seat: Ergonomic air suspension seat absorbs ground vibration to maintain operator comfort and productivity throughout long working sessions.
- Cross Control Lever for Front Hydraulics: Standard fitting for convenient operation of front-mounted implements including front loaders and blades.
- High Ground Clearance (477mm): Confident working over ridges, in tall vegetation, and on rough or undulating terrain.
- Hydraulic 4WD Engagement: Smooth on-the-go switching between 2WD and 4WD via hydraulic multi wet disc clutch for maximum traction when conditions demand it.
- Wet Multi-Disc Brakes Front and Rear: Reliable, consistent stopping performance with and without implement or trailer load.
- Rear Window Wiper: Standard fitting on all RX40P models for improved rearward visibility in wet or dusty field conditions.
- One-Piece Hood: Folds upward for easy access to all routine service points including air filter, fluids, and electrical components.
Specifications
| Specification | Detail |
| Engine Model | Daedong 4H243T-TP5A |
| Engine Type | 4-cylinder turbocharged diesel |
| Engine Gross Power | 73.1hp (54.5 kW) |
| Rated Engine Speed | 2,600 rpm |
| Max Torque | 240.5 Nm |
| Torque Reserve | 20% |
| Displacement | 2,435cc |
| Fuel Tank Capacity | 100 L |
| Transmission | Power Shuttle, 20 forward x 20 reverse |
| Shuttle Type | Power Shuttle (gear lever button) |
| Forward Speed | 0 to 38.3 km/h |
| 4WD System | Hydraulic multi wet disc clutch |
| Brakes | Wet multi-disc (front and rear) |
| Parking Brake | Wet multi-disc |
| Rear PTO Speed | 540 / 540E rpm |
| PTO Type | Independent |
| Rated PTO Power | 60.9hp |
| Maximum PTO Power | 63.5hp |
| 3-Point Hitch Category | Category II |
| Lower Link Type | Quick type |
| Lift Capacity (hitch point) | 2,533 kg |
| Lift Capacity (24 in behind hitch) | 1,963 kg |
| Overall Length (with 3pt and front weight) | 3,990 mm |
| Overall Width (min tread) | 2,140 mm |
| Overall Height (ROPS) | 2,917 mm |
| Wheelbase | 2,170 mm |
| Ground Clearance | 477 mm |
| Turning Radius | 3.92 m |
| Operating Weight (with ROPS) | 2,836 kg |
| Front AG Tyres | 11.2-24 |
| Rear AG Tyres | 16.9-30 |
Typical Applications
The Kioti RX8040P is well suited to mixed and arable farming, livestock management, sports turf and golf course maintenance, local authority estate and roadside management, equestrian properties, and larger-scale groundscare contracts. Its combination of high lift capacity, broad 20-speed range, and independent PTO makes it capable of ploughing, cultivation, mowing, spreading, and year-round property maintenance. Cardiff Lawn and Garden can advise on compatible Kioti front loaders and implements to build the right package for your operation.
Also Known As
Kioti RX8040P tractor, Kioti RX8040 ROPS utility tractor, 73hp utility tractor UK, Kioti Power Shuttle tractor Wales, RX Series 73hp tractor, 4WD utility tractor with PTO UK, mid-range utility tractor Wales, Cardiff Lawn and Garden Kioti, groundscare utility tractor Cardiff, Kioti 73hp farm tractor UK.
